supralast

for Petrochemical Applications

Oil drilling is one of the most complex fields due to the peculiar environmental conditions to be faced by the seal. Huge downtime costs are the fee to be paid in case of breakdown or failure of a sealing element.


In oil drilling plants, depending on the different possible positions, one can find harsh mixtures of hydrocarbons even sulfonated, superheated steam, H2S, CO2, Methane, amine based corrosion inhibitors, temperatures well below 0°C and over 200°C, high pressure.

To cope with so aggressive and diversified combinations the following features must be granted at the same time:

  • chemical resistance
  • outstanding physical properties
  • elasticity in a wide range of temperatures
  • resistance against explosive decompression (AED)

We have a long time experience in solving all kinds of difficult sealing problems inside the Oil & Gas sector.


We have with success made sealing solutions to following equipment this sector:


Ball valves - Gate valves - Butterfly valves - Regulating valves - Plug valves - Seat valves - Check valves - Metering valves - Control valves - Valve actuators – BOP - Couplings for flexible pipes - Xmas trees - Drill drives - Marine cranes.


MCM High-Performance Sealing has a wide range of O-Ring/ rubber gasket and standard PTFE based seals in dimension up to ø 2.300 mm (ø 90”).

As a matter of fact the following elastomers are of common use

FKM, bisphenolic cured

Maximum thermal rating (+240°C), excellent resistance against hydrocarbons also aromatic, good physical properties, limited resistance to steam and H2S (max 2000 ppm). Special compounds for explosive decompression (AED).

FKM, peroxide cured

Excellent thermal rating (+220°C), special grades for low temperatures, good resistance to bases, limited resistance to H2S. Special compounds for explosive decompression (AED).

FEPM, AFLAS®

Excellent thermal rating (+230°C),outstanding resistance against bases and H2S ( up to 30%), limited resistance to hydrocarbons and aromatic substances, limited low temperature flexibility. Special compounds for explosive decompression (AED).

FFKM, evolast®

Outstanding thermal rating (+330°C), outstanding resistance towards aggressive chemicals, acids, organic and inorganic fluids, ketones, esters, solvents, amines, hot water and steam. Special compounds for explosive decompression (AED).

HNBR

Maximum physical properties, good thermal rating (+160°C), good steam and H2S ( max 5000 ppm) resistance, limited resistance to aromatic hydrocarbons. Special compounds for explosive decompression (AED).

Compounds for Petrochemical Applications
